Products Description
Flat Surface Labeling Machine feeds a flat product under the label head, separates the self-adhesive label from the liner, and presses it onto the top or side surface. It is used for flat packs, covers, cards and light boxes before packing or shipment. The core structure includes a stepper motor label feeder, conveyor, sensor, peel plate and elastic pressing unit.
Product Parameters
|
Parameter |
Specification |
|
Suitable Product |
Cards, bags, lids, boxes and other flat products |
|
Labeling Face |
Top face, side face or sample-confirmed flat face |
|
Label Control |
Stepper motor feed with sensor reading |
|
Placement Speed |
More than 50-100 pcs/min, depending on product size |
|
Placement Accuracy |
±3mm, excluding product and label tolerance |
|
Conveyor Length |
1200mm |
|
Platform Height |
600-850mm |
|
Label Roll |
76.2mm inner diameter; 260mm maximum outer diameter |
|
Power Source |
AC220V±5%, 50/60Hz |
|
Operating Environment |
0-50°C; humidity 15-90% |
Product Advantages
The stepper motor feed keeps label release steady during short runs and small-batch changeovers.
Photoelectric detection checks the product position before the label is released, so empty labeling is reduced.
The elastic pressing unit helps the label lie flat on cards, coated lids and thin boxes.
PLC and touch-screen operation make speed, length and label stop settings easier to read on the panel.
The stainless steel and aluminum alloy structure is suitable for daily cleaning in packaging workshops.
Main Applications
This machine is used for paper cards, plastic lids, flat pouches, instruction cards, covers and carton panels.
It is selected when the label needs to sit on a visible flat surface, not around a bottle.
For soft bags or coated boxes, real filled samples should be tested because pressure and surface gloss affect the final edge.
Packaging
- Before delivery, the label head, conveyor and guides are fixed to avoid movement during transport.
- Accessories are counted with the order list and placed in a marked box.
- Outside marks can show infeed direction, operator side and cable side.
FAQ
Q: What samples are needed for Flat Surface Labeling Machine?
A: Product samples, label rolls, label position drawings and the required running direction should be prepared.
Q: Which catalogue accuracy should be expected?
A: The catalogue lists ±3mm, excluding product and label tolerance, so the real sample tolerance is also checked.
Q: Can this machine label soft bags?
A: Yes, but filled samples are better because empty bags do not show the real pressing condition.
