Products Description
The Self Adhesive Labeling Machine separates the label from the release liner and presses the sticky label onto the required product surface. Its working path covers roll loading, tension buffering, web guidance, sensor reading, liner turning, sticker release and final pressing. Because the adhesive is already coated on the label, this equipment is used for barcode labels, product description stickers, warning marks, price labels, carton marks, battery labels, medicine package labels and daily chemical package labels.
Product Parameters
|
Labeling condition |
Reference data |
|
Label stock |
Pressure-sensitive paper label, film label or similar roll stock |
|
Allowed length |
15-300mm |
|
Allowed height |
50-130mm |
|
Speed setting |
0-120 labels/min |
|
Placement accuracy |
+/-0.5mm |
|
Power input |
Single phase 220V, 50/60Hz |
|
Rated power |
0.6kW |
|
Machine dimension |
L2400mm x W1400mm x H1300mm |
Components
Roll holder supports the adhesive stock and keeps the roll in the correct unwinding position.
Tension buffer reduces sudden pulling force when the drive part starts or stops.
Sensor area detects the gap, mark or edge used for label release timing.
Peel plate turns the liner sharply so the sticker can leave the backing paper.
Pressing part finishes the paste action after the label touches the package.
Product Advantages
The Self Adhesive Labeling Machine avoids glue heating, glue mixing and glue tank washing, so short batch operation is easier to arrange.
It is suitable for barcode and traceability work because operators can change printed label rolls without changing the mechanical glue system.
Used backing paper is collected after peeling, keeping the label head area cleaner during continuous work.
The D-1 coder option can be considered when the same label also needs simple date or batch information.
Main Applications
- Electronics packing uses it for battery stickers, accessory labels, circuit board marks and small part identification.
- Retail and warehouse packing uses it for barcode, price, warning and shipping information labels.
- Food, medicine and daily chemical products use it for description labels, lot marks and traceability stickers on regular packages.
FAQ
Does this machine need liquid glue?
No. It works with labels that already have adhesive on the back, which is why the process is peeling, positioning and pressing.
Which label rolls should be tested first?
Transparent film labels, shiny labels and labels with dark backing paper should be tested because sensor response may be different.
How should a Self Adhesive Labeling Machine be selected?
Selection should start from product shape, label size, backing paper, label position, speed plan and whether a coder is required.
