Products Description
Box Labeling Machine guides each box to the label head, reads its position with a sensor, and presses a self-adhesive roll label onto the selected panel. It is used for barcode, product information and shipping labels before the box enters packing, sorting or storage. The machine includes a conveyor, label head, peel plate, sensor and pressing unit.
Product Parameters
|
Parameter |
Specification |
|
Suitable Product |
Cartons, medicine boxes and flat packages |
|
Maximum Carton Size |
L600*W400*H300mm |
|
Label Control |
Stepper motor control and photoelectric detection |
|
Placement Speed |
More than 50-100 pcs/min, depending on carton size |
|
Placement Accuracy |
±3mm, excluding product and label tolerance |
|
Platform Height |
600-850mm |
|
Applicable Labels |
Single-row self-adhesive roll labels |
|
Power Source |
AC220V±5%, 50/60Hz |
|
Optional Function |
Date coding, paging unit or line connection |
|
Inspection |
Release point, label panel and barcode area |
Product Advantages
Side guides help the carton enter the label area squarely, which keeps the label panel more consistent.
The touch-screen control lets operators adjust label length, stop position and speed without changing mechanical parts every time.
A photoelectric sensor checks the carton before release, reducing labels wasted on empty spaces.
The elastic pressing part helps the label corner attach to coated or folded cartons.
The structure can be planned for stand-alone use or linked with a case packing line.
Main Applications
This machine is used for medicine boxes, food cartons, cosmetic cartons, e-commerce boxes and flat retail packages.
It is selected when the label must avoid printed text, barcode blanks or sealing flaps.
For several carton sizes, guide marks can be kept for each accepted sample.
Packaging
- The conveyor, label head and guides are fixed before loading.
- Accessories, tools and spare marks are checked against the packing list.
- Export labels can show line direction and installation side.
FAQ
Q: Can Box Labeling Machine work with printed cartons?
A: Yes. The printed panel and barcode area should be marked so the label does not cover key information.
Q: What maximum carton size is listed in the catalogue?
A: The catalogue table lists L600*W400*H300mm for the carton size.
Q: What affects model selection?
A: Box size, label position, label roll direction, required speed and line height all affect the selection.
